0.5mm Portable Greenhouse Gutter Machine For Hydroponic system

Product Categories

Cold Roll Forming Machine [178]
Cable Tray Roll Forming Machine [50]
Rack Roll Forming Machine [50]
Portable Gutter Machine [50]
Embossing Machine [34]
Purlin Roll Forming Machine [121]
Roller Shutter Forming Machine [51]
Stud Roll Forming Machine [41]
Corrugated Roll Forming Machine [20]
Guardrail Roll Forming Machine [29]
Sandwich Panel Machine [59]
Downspout Machine [48]
Stone Coated Roof Tile Machine [18]
Floor Deck Roll Forming Machine [19]
Roof Roll Forming Machine [99]
Tile Roll Forming Machine [58]
Double Layer Forming Machine [26]
K Span Roll Forming Machine [12]
Slitting Machine [20]
Cut To Length Line [15]

Wuxi Techwell Machinery Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

0.5mm Portable Greenhouse Gutter Machine For Hydroponic system

Name: 05mm Portable Greenhouse Gutter Machine For Hydroponic system
Brand: TECHWELL
Price: 1 USD

Brand Name : TECHWELL

Model Number : TW-GM600

Certification : CE, ISO

Place of Origin : China

MOQ : 1 Set

Payment Terms : 40% T/T in advance, 60% T/T before shipment,

Supply Ability : 20 sets

Delivery Time : 60-70 working days

Packaging Details : Suitable for sea shipping

Forming Material Thickness : 0.5mm-0.7mm

Material type : Painted Galvanized Steel

Material width : 600mm

Forming Stations : 7-8 Stations

Machine type : Mobile Cassette type

Application : For soilless planting vegetables, fruits

Contact Now

Portable Greenhouse Gutter Forming Machine For Hydroponic System for soilless planting vegetables, fruits...

The Characteristic of Greenhouse Gutter Machine

Through TECHWELL team continuous researching, developing, designing, testing, we are the first in China to produce greenhouse gutter rollformer with high quality finished gutter profile and stable production in China. we also provide gutter products and services to greenhouse investors with our self-manufactured portable greenhouse gutter machines. We provide both gutter products and hanging parts, standing parts. The cultivation of many fruits and vegetables in a soillesss enviroment has alleiated the futre problem of food shortages. And TECHWELL team are very happy to be working within this industry.

This portable greenhouse gutter machine is movable caterpillar mounted type machine, which can do site-working at the desired length. And the machine base can rotate 360° and move forward and backword for special site-working requirement.
And the forming machine base structure is quick interchangeable Cassette tyoe structure for different profiles required. And if in future the user want to add new more profiles, just need to buy the cassette type forming part and cutting device.

Gutter Profile

0.5mm Portable Greenhouse Gutter Machine For Hydroponic system

Profile Name	Gutter Profile
Material Type	Painted Galvanized Steel
Material Thickness	0.5-0.7mm
Material Width	600mm
Profile Length	Cut to required length
This gutter profile widely used gutter model for the production of tomatoes, cucumbers and steet bell peppers. And this profile is used in both standing support systems and hanging systems.

The Specification of Greenhouse Gutter Machine

Forming Station:	7-8 Stations
Roller Material:	High grade 45# steel, and roller surface with hard chrome ≥ 0.05mm
Main Motor Power:	7.5KW
Shaft Diameter:	φ75mm
Hydraulic Power:	11KW
Machine Dimension:	≈ 3800mm * 2000mm * 4500mm
Uncoiler Type:	Hydraulic type with 3 Ton weight capacity

Layout Drawing of Portable Gutter Machine

0.5mm Portable Greenhouse Gutter Machine For Hydroponic system

Greenhouse Gutter Machine Pictures

0.5mm Portable Greenhouse Gutter Machine For Hydroponic system
